DATA LOADING, BATCHING, and SHUFFLING (Auto Encoder with dictionary sample in output) TUTORIAL
Prerequisites
To run this tutorial, please make sure the following packages are installed: - PyTorch 0.4.1
- TorchVision 0.2.1
- PIL: For image io and transforms
- Matplotlib: To generate plots, histograms and etc
import torch from torch.utils.data import Dataset, DataLoader from torchvision import transforms, utils from os import listdir from os.path import join from PIL import Image import numpy as np import random import matplotlib.pyplot as plt
DATASET CLASS
torch.utils.data.Dataset is an abstract class representing a dataset. Your custom dataset should inherit Dataset and override the following methods:
- __len__ so that len(dataset) returns the size of the dataset.
- __getitem__ to support the indexing such that dataset[i] can be used to get ith sample.
Let’s create a dataset class for our Auto Encoder dataset. We will read the 'Input' image directory and 'Ground Truth' image directory in __init__ but leave the reading of images to __getitem__. This is memory efficient because all the images are not stored in the memory at once but read as required. Sample of our dataset will be a img_in, img_gt. Our datset will take an optional argument transform so that any required processing can be applied on the sample.
class AutoEncoderDataSet(Dataset):
def __init__(self, dir_in, dir_gt, transform=None):
self.dir_in = self.load_dir_single(dir_in)
self.dir_gt = self.load_dir_single(dir_gt)
self.transform = transform
def is_image_file(self, filename):
return any(filename.endswith(extension) for extension in [".png", ".PNG", ".jpg", ".JPG", ".jpeg", ".JPEG"])
def load_img(self, filename):
img = Image.open(filename)
return img
def load_dir_single(self, directory):
return [join(directory, x) for x in listdir(directory) if self.is_image_file(x)]
def __len__(self):
return len(self.dir_in)
def __getitem__(self, index):
img_in = self.load_img(self.dir_in[index])
img_gt = self.load_img(self.dir_gt[index])
sample = {'img_in': img_in, 'img_gt': img_gt}
if self.transform:
sample = self.transform(sample)
return sample
torchvision.transforms.Compose is a simple callable class which allows us to composes several transforms together. We will use a RandomCrop(128), RandomHorizontalFlip(), RandomVerticalFlip(), RandomRotate(), and ToTensor() classes. We will push transform function to our AutoEncoderDataSet class as:
composed = transforms.Compose([RandomCrop(128), RandomHorizontalFlip(), RandomVerticalFlip(), RandomRotate(), ToTensor()])
auto_encoder_dataset = AutoEncoderDataSet(ps['DIR_IMG_IN'], ps['DIR_IMG_GT'], composed)
torch.utils.data.DataLoader is an iterator which provides all these features:
- Batching the data.
- Shuffling the data.
- Load the data in parallel using multiprocessing workers.
We will apply all these features in single line of code:
data_loader = DataLoader(auto_encoder_dataset, batch_size=5, shuffle=True, num_workers=4)
Let’s instantiate this class and iterate through the data samples.
def main(ps):
plt.close('all')
composed = transforms.Compose([RandomCrop(128), RandomHorizontalFlip(), RandomVerticalFlip(), RandomRotate(), ToTensor()])
auto_encoder_dataset = AutoEncoderDataSet('img/tr/in/', 'img/tr/gt/', composed)
data_loader = DataLoader(auto_encoder_dataset, batch_size=5, shuffle=True, num_workers=4)
for i_batch, sample_batched in enumerate(data_loader):
print(i_batch, sample_batched['img_in'].size(), sample_batched['img_gt'].size())
if i_batch == 1:
show_batch(sample_batched['img_in'], 1, 'Input batch from DataLoader')
show_batch(sample_batched['img_gt'], 2, 'Ground truth batch from DataLoader')
plt.axis('off')
plt.ioff()
plt.show()
Out:
The full example code:
import torch
from torch.utils.data import Dataset, DataLoader
from torchvision import transforms, utils
from os import listdir
from os.path import join
from PIL import Image
import numpy as np
import random
import matplotlib.pyplot as plt
class ToTensor(object):
"""Convert ndarrays in sample to Tensors."""
def __call__(self, sample):
img_in, img_gt = sample['img_in'], sample['img_gt']
# swap color axis because
# numpy image: H x W x C
# torch image: C X H X W
img_in = np.asarray(img_in)
img_in = img_in.transpose((2, 0, 1))
img_gt = np.asarray(img_gt)
img_gt = img_gt.transpose((2, 0, 1))
return {'img_in': torch.from_numpy(img_in), 'img_gt': torch.from_numpy(img_gt)}
class RandomRotate(object):
"""Rotate the given PIL Image randomly with a given probability.
Args:
p (float): probability of the image being rotated. Default value is 0.5
"""
def __init__(self, p=0.5):
self.p = p
def __call__(self, sample):
"""
Args:
sample {img_in PIL Image, img_gt PIL Image}: Images to be rotated.
Returns:
{img_in PIL Image, img_gt PIL Image}: Randomly rotated images.
"""
img_in, img_gt = sample['img_in'], sample['img_gt']
if random.random() < self.p:
angle = random.choice([Image.ROTATE_90, Image.ROTATE_180, Image.ROTATE_270])
img_in = img_in.transpose(angle)
img_gt = img_gt.transpose(angle)
return {'img_in': img_in, 'img_gt': img_gt}
class RandomVerticalFlip(object):
"""Vertically flip the given PIL Images randomly with a given probability.
Args:
p (float): probability of the image being flipped. Default value is 0.5
"""
def __init__(self, p=0.5):
self.p = p
def __call__(self, sample):
"""
Args:
sample {img_in PIL Image, img_gt PIL Image}: Images to be flipped.
Returns:
{img_in PIL Image, img_gt PIL Image}: Randomly flipped image.
"""
img_in, img_gt = sample['img_in'], sample['img_gt']
if random.random() < self.p:
img_in = img_in.transpose(Image.FLIP_TOP_BOTTOM)
img_gt = img_gt.transpose(Image.FLIP_TOP_BOTTOM)
return {'img_in': img_in, 'img_gt': img_gt}
class RandomHorizontalFlip(object):
"""Horizontally flip the given PIL Images randomly with a given probability.
Args:
p (float): probability of the image being flipped. Default value is 0.5
"""
def __init__(self, p=0.5):
self.p = p
def __call__(self, sample):
"""
Args:
sample {img_in PIL Image, img_gt PIL Image}: Images to be flipped.
Returns:
{img_in PIL Image, img_gt PIL Image}: Randomly flipped image.
"""
img_in, img_gt = sample['img_in'], sample['img_gt']
if random.random() < self.p:
img_in = img_in.transpose(Image.FLIP_LEFT_RIGHT)
img_gt = img_gt.transpose(Image.FLIP_LEFT_RIGHT)
return {'img_in': img_in, 'img_gt': img_gt}
class RandomCrop(object):
"""Crop the given PIL Images randomly."""
def __init__(self, output_size):
assert isinstance(output_size, (int, tuple))
if isinstance(output_size, int):
self.output_size = (output_size, output_size)
else:
assert len(output_size) == 2
self.output_size = output_size
def __call__(self, sample):
"""
Args:
sample {img_in PIL Image, img_gt PIL Image}: Images to be cropped.
Returns:
{img_in PIL Image, img_gt PIL Image}: Randomly cropped image.
"""
img_in, img_gt = sample['img_in'], sample['img_gt']
w, h = img_in.size
new_h, new_w = self.output_size
top = np.random.randint(0, h - new_h)
left = np.random.randint(0, w - new_w)
img_in = img_in.crop((left, top, left + new_w, top + new_h))
img_gt = img_gt.crop((left, top, left + new_w, top + new_h))
return {'img_in': img_in, 'img_gt': img_gt}
class AutoEncoderDataSet(Dataset):
def __init__(self, dir_in, dir_gt, transform=None):
self.dir_in = self.load_dir_single(dir_in)
self.dir_gt = self.load_dir_single(dir_gt)
self.transform = transform
def is_image_file(self, filename):
return any(filename.endswith(extension) for extension in [".png", ".PNG", ".jpg", ".JPG", ".jpeg", ".JPEG"])
def load_img(self, filename):
img = Image.open(filename)
return img
def load_dir_single(self, directory):
return [join(directory, x) for x in listdir(directory) if self.is_image_file(x)]
def __len__(self):
return len(self.dir_in)
def __getitem__(self, index):
img_in = self.load_img(self.dir_in[index])
img_gt = self.load_img(self.dir_gt[index])
sample = {'img_in': img_in, 'img_gt': img_gt}
if self.transform:
sample = self.transform(sample)
return sample
def show_batch(sample_batched, fig_pos, plt_name):
plt.figure(fig_pos)
grid = utils.make_grid(sample_batched)
plt.imshow(grid.numpy().transpose((1, 2, 0)))
plt.title(plt_name)
def main(ps):
plt.close('all')
composed = transforms.Compose(
[RandomCrop(128), RandomHorizontalFlip(), RandomVerticalFlip(), RandomRotate(), ToTensor()])
auto_encoder_dataset = AutoEncoderDataSet(ps['DIR_IMG_IN'], ps['DIR_IMG_GT'], composed)
data_loader = DataLoader(auto_encoder_dataset, batch_size=5, shuffle=True, num_workers=4)
for i_batch, sample_batched in enumerate(data_loader):
print(i_batch, sample_batched['img_in'].size(), sample_batched['img_gt'].size())
if i_batch == 1:
show_batch(sample_batched['img_in'], 1, 'Input batch from DataLoader')
show_batch(sample_batched['img_gt'], 2, 'Ground truth batch from DataLoader')
plt.axis('off')
plt.ioff()
plt.show()
if __name__ == "__main__":
ps = {
'DIR_IMG_IN': 'img/tr/in/',
'DIR_IMG_GT': 'img/tr/gt/'
}
main(ps)
REFERENCES:
